Data logger AIM EVO5 with integrated GPS08 Roof module 2m and CAN, RS232 or K Line connection
Brand: Aim

Data logger AIM EVO5 with integrated GPS08 Roof module 2m and CAN, RS232 or K Line connection

Code: X62EVO520R

2.034,96€ -8% SAVINGS 162,80€
1.872,16 VAT PRICE & Free shipping to Italy
or 3 installments of 624.05 € without interest Pay with ScalapayInfo su Scalapay
Available in 5-7 working days
* delivery times are variable and depend on the availability of the goods and the delivery time of the courier.
ASK FOR INFO
*Non-EU customers, do not pay VAT. (you will pay the VAT in your own country upon receipt of the goods in accordance with local taxation)

EVO5 professional data acquisition

 Code: X62EVO520R

AIM EVO5 has over time become the reference data logger in many leagues around the world. Technology collected in a compact and sturdy aluminum structure is easily installed on any type of vehicle. It too is simple and intuitive to use thanks to the help of the software supplied with Race Studio 3.

Data from different sources

EVO5 also provides all the information coming from the ECU via CAN, RS232 or K-line from the integrated accelerometer and gyroscope and from the GPS08 included in the kit. It also manages the analogue/digital inputs and predefined mathematical channels, the performance and the quantity of data can be further increased by using the 8 expansion modules produced by AIM.

Two digital outputs

The EVO5 has two 1 A digital outputs, which can be switched off or on depending on analog, digital or CAN inputs. It is therefore possible to manage external systems such as additional warning lights, cooling fans or pumps when a certain event occurs.

Internal SD card

The internal SD card (not included) allows the storage of most data, protected from the weather through a waterproof door. Data is always safe, thanks also to the adoption of a sensor that automatically closes and saves files, making it impossible to lose data. To download the data, simply remove it from its door and insert it into a PC. It is possible in any case to import data via USB interface.

WI-FI connectivity

the EVO5 can be connected through a secure WI-FI network through its own computer, so as to be able to download data quickly and safely up to a distance of 100 meters

Two multi-channel Motorsport connectors

Two Motorsport multi-channel connectors: one professional wiring for ALL your connections, easy to install and manage. A 37-pin connector for the main applications (power supply, CAN, AiM CAN network, etc.) and a 22-pin connector for additional functions such as CAN2, digital inputs, etc.

CAN output

With the CAN output function you can expand the vehicle control range, with the possibility of adding:

LCU-One CAN

  • LCU Wide band lambda controller, equipped with a probe: transmits all information on the Air/Gasoline ratio, lambda probe value and exhaust gas temperature allowing engine tuning.

SmartyCam HD cameras

  • The on-board cameras that read the data from the system and automatically superimpose them on the video for an even more precise reading.

Memory Module

  • It is a support for SD cards useful for recording data from the AIM logger during track sessions. More generally, all the sensors needed to increase EVO4S performance.

Display available

To be able to view the data in real time it is possible to connect the EVO4S to the GS-Dash display or to the Formula Steering Wheel 3 instrumented steering wheel.

Download and analyze your data in a professional manner

Evo4S data can be analyzed with Race Studio Analysis software: it will be possible to evaluate its performance through histograms and tables, so as to have a fundamental help for the development of the vehicle as well as improving driving techniques.

Features:

8 fully configurable analog inputs, digital inputs (coil RPM and 4 speed inputs), 2 digital outputs, second CAN, integrated 3 axis ±5G accelerometer + 3 axis gyro, CAN, RS232 or K Line ECU connections, CAN protocol for external expansion modules,Wi-Fi connection, internal memory 4 GB, anodized aluminum body, IP65.

  • ECU connection: CAN, RS232, K-Line
  • External modules connection: GPS Module, Channel Expansion, TC Hub, Lambda controller, SmartyCam HD
  • Analog inputs: 8 fully configurable: 0-5V, 0-12V, K thermocouples.  Max freq 1 KHz each
  • Digital inputs: Coil RPM and 4 speed inputs
  • Inertial platform: Internal 3 axis ±5G accelerometer + 3 axis gyro
  • Digital outputs: 2, up to 1 A each
  • Second CAN: Yes
  • Wi-Fi connection: Yes
  • Internal memory: 4 GB
  • SD card: Internal: up to 128 GB (not included)
  • Connectors: 2 Motorsport
  • Body: Anodized aluminum
  • LEDs: 1 system status
  • Dimensions: 114.4x47.2x58.8 mm
  • Weight: 300 g
  • Waterproof: IP65

In the box:

EVO5, SD card, 37 pin harness, USB cable, GPS08 Module, mounting bracket, Race Studio 3 software CD.

INSTALLATION

To install EVO5 from AIM it is important to follow small steps. Initially configure with Race Studio 3 and only then connect the CAN, serial or K line. For the accelerometer to function correctly, it is essential to position the Evo5 in a central position as close as possible to the vehicle's center of gravity. The GPS module should not be installed underneath metal or carbon fiber objects, they would act as a shield reducing the satellite signal. Also avoid installation near digital cameras, antennas or TFT displays.

Do not install EVO5 with live cables.

Suitable for:
