MXm AIM's most compact dash logger

 Code: X87MXM0000

Complete data reception

ECU, GPS and internal inertial platform send their data to the MXm for direct processing, the instrumentation is also equipped with 4 configurable analogue channels, 3 digital channels divided into 2 speed channels and 1 RPM and predefined mathematical channels. For those who demand the maximum, the MXm can be connected to the Lambda controller and the SmartyCam HD so as to exploit the instrumentation to its full potential..

MXm includes integrated alarms and shift light

the AIM MXm is equipped with 5 configurable RGB LED alarms, so it will be possible to choose the color and the values that determine the activation. It is possible for example to decide that they turn on in the event of a better time or split time on the track or to choose the best time for the gear change. 2 additional LEDs that can be set to flashing or fixed light can be configured for all the driver's needs.

High power for 2 separate digital outputs

The standard equipment of 2 digital outputs allow the AIM MXM to manage a 15 A command on each single channel it is possible to switch them off or switch them on depending on analog, digital or CAN inputs. It is therefore possible to manage external systems such as additional warning lights, cooling fans or pumps when a certain event occurs.

High legibility for a large LCD screen

A large 268x128 pixel graphic display allows an easy, clear and always precise reading of the displayed data, with the help of the brightness sensor the MXm will always adapt to any light condition to allow a better contraction and clarity. The screen can also be set with one of the seven colors available via backlight.

View your data directly on the screen

It is possible to organize data as you prefer with the help of customizable pages, at the end of each session it will be possible to control various fundamental parameters such as lap times for temperatures and minimum and maximum RPM values reached

WI-FI connectivity

the MXm can be connected via a secure WI-FI network via its own computer, so that data can be downloaded quickly and safely up to a distance of 50 meters

MXm can be connected to:

LCU-One CAN

• LCU Wide band lambda controller, equipped with a probe: transmits all information on the Air/Gasoline ratio, lambda probe value and exhaust gas temperature allowing engine tuning.

SmartyCam HD cameras

• The on-board cameras that read the data from the system and automatically superimpose them on the video for an even more precise reading.

Race Studio 3,  the perfect software for your AIM

With the Race studio 3 it is possible:

• Create, modify, delete, import and export configurations with all channels, the drivers of the control unit, the mathematical channels, the display pages, the digital outputs, the alarms, the shift lights and all the desired expansions. It is also possible to manage the maps of all your favorite circuits and compare two laps on the same track by watching the videos recorded by the SmartyCam HD and GP HD cameras.

Features:

High contrast LCD, 7 configurable RGB backlight colors, ambient light sensor, 2 configurable RGB alarm LEDs, 5 configurable RGB shift light LEDs, 2 CAN connections, connection to 1,000+ industry leading ECUs, 4 fully configurable analog inputs, 3 digital inputs, 2 digital high-side outputs, integrated GPS, inertial platform, 4 GB internal memory, IP65.

• Display resolution: 268 x 128 pixels
• Backlight: 7 configurable RGB colors
• Ambient light sensor: Yes
• Shift lights: 5 configurable RGB LEDs
• Alarm LEDs: 2 configurable RGB LEDs
• CAN connections: 2
• ECU connections: CAN, RS232 or K-Line
• ECU compatibility: +1,000 industry leading ECUs
• GPS: Integrated
• External modules: Lambda Controller and SmartyCam HD
• Analog inputs: 4 fully configurable, max 1,000 Hz each
• Digital inputs: 2 speed inputs, coil RPM input
• Digital outputs: 2 high-side
• Inertial platform: Internal 3 axis ±5G accelerometer + 3 axis gyro  + 3 axis magnetometer: Wi-Fi connection: Yes
• Internal memory: 4 GB
• Body: Glass fiber reinforced Nylon
• Pushbuttons: Metallic
• Connectors: 37 pins Motorsport connector + 4 pins power connector
• Dimensions: 137x88.4x31.9 mm
• Weight: 330 g
• Waterproof: IP65

In the box:

MXm, USB cable, 37 pins connector harness, DTP 06-4S EE01 4 pins connector with pins, Race Studio 3 software, user manual.
