Brembo Racing RCS19 radial brake pump kit with reservoir tank and bracket and DOT4 brake oil

Brembo Racing RCS19 radial brake pump kit with reservoir tank and bracket and DOT4 brake oil

Code: 110A26310+110A26385+04816450

468,11€ -38.69% SAVINGS 181,11€
287,00€ VAT PRICE & Free shipping to Italy
or 3 installments of 95.67 € without interest Pay with ScalapayInfo su Scalapay
Available on Stock
* delivery times are variable and depend on the availability of the goods and the delivery time of the courier.
*Non-EU customers, do not pay VAT. (you will pay the VAT in your own country upon receipt of the goods in accordance with local taxation)

Brembo 19RCS brake pump system kit complete with reservoir tank, bracket and oil

The complete Brembo brake system kit consists of:

  • 19 RCS clutch master cylinder
  • Tank bracket
  • Brake oil reservoir
  • Brake / clutch fluid oil DOT4
  • Idrostop

Brembo RCS front brake system kit

The Brembo RCS radial brake pump allows you to choose powerful or modular braking according to road conditions, weather conditions, your sensitivity, the feeling you have with the bike. This is a patented master cylinder, directly derived from the one used in MotoGP, which thanks to the innovative adjustment system allows the same master cylinder to be adapted to the different uses of customers, even the most demanding ones.

The RCS system consists of a register with which it is possible to change the lever distance to 18 or 20 mm, in order to achieve the ideal feeling between rider and motorcycle: by varying the wheelbase, in fact, it is possible to make the braking system more reactive and ready (int. 20) or more modular (int. 18).

The configuration change is very quick: just adjust the pump center distance by turning the adjuster located on the front of the guide lever by 180 degrees with a screwdriver, with the eccentric system (red on 18 mm, black on 20 mm): from this derives a different distribution of the braking force without modifying its pure power.

The piston, the gaskets and the tip of the RCS pumps are the same as the pumps used by almost all the MotoGP and SB riders, characterized by very low machining tolerances and excellent smoothness. The lever, on the other hand, is made up of two main components: the Racing Lever guide and the lever itself, articulated, made through forging.


  • Material: Forged aluminum
  • Type: Brembo RCS19 master cylinder
  • Piston diameter: 19mm
  • Variable lever distance: 18-20mm
  • Lever type: LONG LEVER
  • Single/Double Disc: Double
  • Surface protection: Hard anodizing
  • Weight: 350gr
  • Brake light microswitch: Yes
  • Ø Handlebar fixing (mm): 22.2
  • ABS Compatible
  • Bleed screw tightening torque: 12÷16 Nm

Customer Review
5 of 5
Friday 15 July, 2022 / Carsten Dyrmose
Works perfect on my R1 2005 !! Alot better braking feeling vs standard.
