KOSO DL-03SR black LCD universal digital dashboard

The KOSO D64 DL-03SR is a multifunction speedometer for motorcycles with ABE and KBA certifications. It integrates tachometer, speedometer, signal indicators, and advanced features in a sleek design. Includes fuel gauge, voltage monitoring, tank learning mode, and visual alerts for enhanced convenience and safety.

Key Features:

• Speed: up to 360 km/h (223 MPH).
• Tachometer: up to 15,000 RPM with precise indicators.
• Integrated signals: indicators for turn signals, high beam, oil, EOBD, and neutral.
• Multifunctionality: fuel and voltage measurement.
• Compact design: easy to install on any vehicle.

Technical Specifications:

• Speedometer:
  • Speed range: 0-360 km/h (0-223 MPH).
  • Odometer: 0-99,999.9 km (miles), automatic reset.
  • Trip A/B: 0-999.9 km (miles).
  • Tire circumference: adjustable from 300 to 2,500 mm (1 mm precision).
  • Sensor pulses: 1-60.
• Tachometer:
  • Range: 0-15,000 RPM.
  • Unit: 1 segment = 1,000 RPM.
• Fuel gauge:
  • Levels: 4.
• Digital voltmeter:
  • Range: DC 5-28 V.
• Clock: 24h format.
• Dimensions: 70 mm x 35 mm x 50 mm (outer x depth x installation diameter).
• Signal indicators:
  • Turn signals, neutral, oil, high beam, EOBD.
