Solo 2 DL AIM's new GPS lap timer

 Code: X47SOLO2DL01

The Solo 2 DL uses combined data from 2 GPS and Glonass satellites, incredibly faster and more accurate than the previous version. It is ready to use in a few seconds and calculates lap times with a maximum deviation of 2 thousandths of a second. The display can be backlit in 7 different colors according to your preferences.

Your track with GPS & Glonass networks

Inside the memory of the Solo 2 DLthere are 3000 circuits from all over the world, when switched on, the Solo 2 DLchecks its position and, recognizing the coordinates of the finish line, the acquisition of the times begins. If the track is not present in the database, the Solo 2 DLautomatically enters the self-learning mode, recognizes the characteristics of the track and detects the times perfectly.

Fully manageable RGB LEDs

The configurable RGB LEDs give a clear and quick indication of the comparison with the best lap.

Selection of the type of race

With Solo 2 DL it is possible to manage 2 types of race:

• Speed races on closed circuit
• Performance competitions (0-100 km / h etc.)

For each configuration the right information is provided during the test and the data recall after each session

Data via display

At the end of the tests you can quickly review all the information on the display.

Wireless communication with PC

Quick and easy wireless connection useful to configure the Solo 2, manage the database of the tracks and export the data to the computer Solo 2 DL with ECU communication

Over 1000 protocols for as many ECUs in memory; The Solo 2 DL connects easily and with only one cable to the engine control unit. If the communication protocol is not present in the database, it can be created through the Race Studio 3 Software through the ECU Drive builder.

Only 2 DL RPM coil input

Only 2 DL now has a digital input that allows recording of the RPM signal both from square wave (8-50V signal) and from pulses (150-450 V ignition switch - primary circuit).

Only 2 DL SmartyCam HD connection

This connection takes the data directly from the ECU. it combines them with GPS information, transmitting everything to the SmartyCam HD which will visualize them with a graphical Overlay chair.Specific Bar Pads for motocross

For an even smoother installation AIM has designed motocross bar pads to be easily mounted on the handlebar with or without crossbar.

Features:

GPS Lap Timer with integrated track database and datalogger connectable to the ECU. internal 3 axis ±5G accelerometer + 3 axis gyro + 3 axis magnetometer, 4 GB memory, internal rechargeable lithium battery, magnetic support. Connectable to the ECU via CAN/RS232 and OBDII-K Line, IP67.

• Display: Graphical
• Display resolution: 238x99 pixels
• Display pages: Up to 5 freely configurable
• Backlight: 7 configurable RGB colors
• Shift lights/alarm LEDs: 10 configurable RGB LEDs
• Integrated track database: Yes
• Inertial platform: Internal 3 axis ±5G accelerometer + 3 axis gyro + 3 axis magnetometer
• Wi-Fi connection: Yes
• GPS: 10 Hz
• External power: 12 V
• Memory: 4 GB
• Battery type: Rechargeable Lithium
• Pushbuttons: Metallic
• Dimensions: 98.0x73.7x30.2 mm
• Weight: 240 g, battery included
• Waterproof: IP67
• ECU connection: CAN, RS232 or K-Line to 1,000 + industry leading ECUs

In the box:

• Solo 2 DL, power cable with AC adapter, mounting bracket with screws, user manual, software installation CD, AiM sticker.
